Netgear has introduced its newest member of the AirCard 790s to the router family. The Netgear AirCard 790S is the first mobile hotspot in Aircard 7X0s who supports the LTE Cat6 with up to 300 Mbit/s in the download. Actually, Netgear 790S is not the first LTE cat6 mobile hotspot because Huawei had presented the Huawei E5786, which is the first one.
Features and characteristics of the AirCard 790S |
|||
| Manufacturer and type designation: | Netgear AirCard 790S | ||
| Chipset: | Qualcomm MDM9230 | ||
| LTE Category: | CAT6 | ||
| Download rate: | Up to 300 Mbit/s | ||
| Upload rate: | 50 Mbit/s | ||
| supported LTE bands: | FDD-LTE 700 MHz / 1800 MHz / 2600 MHz | ||
| Backward compatible with: | LTE CAT4 / DC-HSPA+ / UMTS / GSM | ||
| Support of LTE-Advanced: | Yes | ||
| MIMO Support: | 2x2 MIMO | ||
| External antenna connector: | Dual TS-9 for 4G/3G(Buy Netgear Aircard 790s Antenna) | ||
Telephone |
|||
| With integrated telephone system: | no | ||
| Connector for ISDN telephones: | no | ||
| Connection for analog telephones: | no | ||
| DECT: | no | ||
| integrator answering machine: | no | ||
Network | LAN & WLAN |
|||
| LAN Ports: | no | ||
| WLAN Standards: | WiFi 802.11 b/g/n/ac | ||
| 5 GHz WLAN support: | Yes | ||
| Encryption: | WPS, WEP, WPA, WPA2 | ||
| Wireless Internet Hotspot function: | Yes, for up to 15 devices | ||
Others |
|||
| Battery pack: | 2,930 mAh, exchangeable | ||
| Dimensions: | 110 x 68 x 15 mm | ||
| USB: | Micro-USB 3.0 | ||
| Memory card expansion: | no | ||
| available at: | www.4gltemall.com | ||
Technical Features
The AirCard 790s is equipped with a 2.4-inch, color LCD touch screen. The screen displays the network icon, signal strength, the network name, the wireless status, battery status or data usage. And the touch icons takes you to the Settings and other menu items. The router can also be configured on the PC or via an app on your smartphone or tablet and use. The AirCard app is available for iOS, Android and Kindle. Here you can retrieve all possible information.
LTE-Advanced with 300 Mbit/s
The AirCard 790S Netgear supports LTE Category 6, backward with both 2G and 3G networks, including DC-HSPA+. If you live in an area covered with LTE-A field and has a micro-SIM card with an appropriate data plan, using Carrier Aggregation, two 20 MHz bands are combined into a 40-MHz band in downlink, so as to allow download speeds of up to 300 Mbit/s. Carrier aggregation of 2 x LTE2600 is supported as well as the pooling of 2.600 and 1.800 MHz.
Additionally, the AirCard 790S also widespread in the US 700 MHz band used for LTE-A: The router is thus prepared. In upload, up to 50 Mbit/s are possible with the hotspot. If the wireless coverage at home or on the go too weak, user can connect two external antennas for 3G/4G to the router.
Supply 15 devices with fast Wi-Fi
The Netgear 790S supports the standard Wi-Fi ac on 2.4 and 5 GHz. As a hotspot, the router can support up to 15 devices with wireless Internet while other competing models supports maximum devices to 10 units. The network can be encrypted with WPA2, which is set by WPS. If you connect the router via USB 3.0 to a computer, it can be charged at the same time and provide the PC with high speed internet.
Strong and Replaceable Battery
Netgear has his latest AirCard model a strong power source: The battery has capacity of 2,930 mAh, which should be enough for up to 10 hours in operation and 350 hours in standby according to the manufacturer. The router can be charged via the included Micro-USB cable, the 790S also can be used as a charging station for a smartphone itself. The battery is fortunately interchangeable; Netgear offers optional at an even stronger battery with up to 16 hours of run time.
Availability
The AirCard 790S Netgear is available on www.4gltemall.com . And it’s the unlocked version, which means it can work well in North American, Asia and European countries.
Conclusion
The AirCard 790S Mobile Hotspot Netgear has a high-speed router at the start, which is not only fast, but also future-proof. LTE Cat6 and WLAN ac plus support for the 700 MHz band and supply of 15 devices with Wi-Fi, users do not have to provide a lot of competitors. What’s more, the 790S is quite handy and provides an informative color touch display. It’s a real practical and cool 4G pocket router!
Appearance
The Huawei E5770 Mobile WiFi Pro comes in a turquoise cardboard box. In the package, there is a PSU with USB port, a microUSB charging cable and a Quick Start Guide and safety information. At first glance, the Huawei E5770 looks quite large with 200 grams, at least in comparison with other mobile LTE hotspots such as the Huawei E5377. This is mainly due to the exceptionally strong battery that is not replaceable by the way. The Huawei E5770 is manufactured in black or white and completely made of plastic. The following are the technical data in the overview:
Operation & Software
The operation of the Huawei E5770 is very simple. The SIM card must be plugged like an optional memory card under the removable rear panel. There you can find the activated WLAN password, and the address for the Web Interface and the password required for this. The SIM card is inserted together with the MicroSD card on the back. The operation and configuration via the web interface is quick and easily, both on desktop computers and on Tablet touchscreen. On the start screen, the consumed data volume and online time is displayed, on request you can have a look at detailed statistics or tariff limits deposit. It is also possible to receive and send SMS. Navigate to the tab "Settings"; you can set your machine accurately, about the wireless connection or the RJ45 Ethernet connection.
WLAN and Ethernet
The Huawei E5770 Mobile WiFi Pro offers three ways to access the Internet. First of course there's the classic access via the mobile network so that up to 150 MBit/s accessible via LTE Cat4. Then you can also use the RJ45 Ethernet port as Internet access, which offers network connection at home, office or hotel. The third way to access the Internet is the so-called Wi-Fi Extender: the Huawei E5770 thus uses an existing wireless network to access internet.
All three types of access have worked well and without any problems in the test. Particularly interesting is the WiFi Extender function, because then it is also possible to connect multiple devices to a wireless network. As soon as the wireless network, the Huawei E5770 automatically switches from LTE to Wi-Fi access. Huawei E5770 could support up to 11 devices simultaneously. In LTE network, the Huawei E5770 Mobile WiFi Pro Router provides a good reception and many supported frequency ranges, so that it can also be used abroad in many countries. Huawei E5770 would support LTE Advanced Cat4 and the LTE modem Cat4 could achieve 140Mbit/s in the test. It’s a pity that it can’t support LTE CAT6, also disappointed that Huawei mobile WiFi Pro doesn’t have connections for an external antenna.
Battery and More
With the amazing 5,200 mAh strong battery, the Huawei E5770 Mobile WiFi may be used up to 20 hours per operating as a mobile LTE hotspot. The full-size USB port allows charging other devices such as smartphones or tablets. Through the output of 5V / 2A, the charging goes very quickly. The battery capacity is proudly advertised. But the battery can’t be removed. Finally, a little word to the display on the front of the Huawei E5770: this is definitely smaller than many other mobile wireless hotspots of Huawei, but it does the job properly and provides all important information such as data usage and battery status clearly. With a short press on the power button, you can see the wireless password in screen.
Conclusion: A perfect solution for Travel
The Huawei E5770 is a good mobile LTE router with two great unique features: it is the first device of its kind with RJ-45 LAN port and simultaneous support for LTE and it is one of the few devices, which simultaneously can also be used as a power bank for charging other devices. Overall, the router can convince definitely, besides the classic functions of the wireless Extender function should be emphasized. But there are three drawbacks: the missing of 5GHz WLAN and connections for an external antenna, and the feature of LTE Cat6 with 300 Mbit/s is not supported. Even though, the Huawei E5770 Mobile WiFi Pro is still a wonderful pocket WiFi router!
If you want the LTE cat6,
